Jewellery Making Machine

Laser Type

Pulsed Fiber Laser

Average output power
Wavelength

20 W (Optional 5/10/30/50 W)
1064 nm

Output Power Stability (Typical)
Power Adjusting Range

5%
1 ~ 100

Resolution Frequency
Beam Quality (M2)

20-80 KHz
< 2

Output Beam Diameter ( 1/e2)
Max. Linear Speed

6-9 mm
8000 mm/s

Marking Depth
Min. Line Width

0.01~0.3 mm (Material Depended)
003mm

Min. Character Height
Repetition Accuracy

0.2 mm
0.2 pm

Work Station / Table

Marking Area

150 x 150 (Optional 220 x 220/ 300 x 30omm)

Working Table

450 mm X 450 mm

Remote Based Up Down

Load Capacity up to 100 kg

Max Up Down

300 mm

Electrical

Power Supply Single Phase

220V / 50Hz

Power Consumption

500 W

Ambient Temperature Range

0° to 25°C

Cooling System

Air Cooling System

Attachment

Rotary Attachment

Yes (Optional)

Foot Switch

Yes

Red Alignment Laser

Yes

Support Custom Automation

Yes (Based on requirements)

Computer Specification

System

Intel i3 CPU

Configuration

Higher

Monitor

17" square LCD

Accessories

Yes

Dimension

Length X Width X Height

1100 mm x 540 mm x 1400 mm

Weight

110 kg
