Specification :
Laser Source | 75 W CW |
Laser Type | DPSS |
Diode | Hi-Tech / Northrop Grumman / Premium |
Wavelength | 1064 mm |
Beam Mode | TEM 00 |
Q-Switched O/P | 24 Watt @ 10 KHz |
Beam Polarization | Linear |
Pulse Repetition Rate | 1 to 20 KHz |
Laser Class | IV |
CNC System | |
Axis Travel ( X,Y,Z | 130 x 130 x 70 mm |
Resolution | 4000 steps / mm |
Accuracy | + 2 micron |
Repeatability | + 1 micron |
Drive | AC / DC Servo |
Electrical | |
Power Consumption | 1 Phase, 230V AC, 12-15 AMP, 1.8 KW |
Temperature | 20oC to 30oC |
Chiller Cooling Capacity | 1200 Watt |
Dimension | |
Length x Width x Height | 1560 mm X 650 mm X 1450 mm |
Weight | 300 Kg (Approx) |
Computer specification | |
Processor | Intel ® Core i3 |
Screen | 17 Inch LCD |
Resolution | Higher |
